Console:

• Windows base CNC control system
• Remote maintenance.
• Huge order saving.
• Trouble-shooting.
• Optimized order memory.
• Production and order management.
• Available to connect with the customer internal ERP.

Feeding Unit:

• Operation can be controlled by both main console and each unit touch screen.
• Lead-edge feeding, adjustable air control, precious registration
• Precious liner guideway lateral moving
• Motorized side squaring and paper support
• Powerful dust remover, with anti-static bar, centralized dust collection, less ECT loss.

Printing Unit：

• Operation can be controlled by both main console and each unit touch screen.
• High precious transfer structure with ceramics vacuum transfer wheel, good registration accuracy.
• Printing plate mounting when machine is running,safety protect cover synchronized lifting, quick and safe order change, productivity and efficiency.
• Quick printing plate mounting, motorized phase zero.
• Double doctor blade, quick spraying anilox roll washing and ink saving system.
• Fixed printing unit machine but openable –easy to do maintenance and add printing Unit

Creasing Unit:

• Operation can be controlled by both main console and each unit touch screen.
• Liner guideway lateral moving device with universal cross joints.
• Precious ballscrew shaft, high rigid guiding cast, long lifetime.
• Pre-creaser, Big Pre-creaser, creaser, prevent creasing line from bursting, better folding.
• Motorized gap control, large displacement of middle knife.

Slotting Unit:

• Thin Creaser And Slotter.
• Two Shafts Slotter Structure For More Flexible
• Linear Guideway Lateral Moving Device
• Ball Screw Shaft.

Features Included:

• Auto Zero Set.
• Two Shafts Knife Slotter Structure.
• Creaser Roll Motorized Adjustment With Digital Display
• Slot Shaft Gap Motorized Adjustment With Digital Display
• Center Slot Head Movable, With Long Distance
• Box Height And Slotter Register Motorized Controled By Plc
• Use 7.5mm Thickness Slotter Knife.

Die-cutting Unit:

• Operation can be controlled by both main console and each unit touch screen.
• Die-cutting roll pneumatic self-locking device.Die-cut pressure motorized control
• U.E quick change die-cut anvil with grinding mechanism.
• Precious settable speed difference compensation, ensure die-cutting accuracy.

FOLDER & GLUER

• Features Included:
• Auto Zero Set
• Softener With Rotary Brushes To Clean The Scrap.
• Big Gluing Wheel, Constant Temperature Glue System, Liner
• Guideway Lateral Moving System.
• Motorized Control Glue Wheel Position, Reticulation Gluing.
• Belt Press Wheel, Motorised Control Gap Adjustment According To Board Thickness.
• Folding Guide Wheel Correct Fish Tail.
• Vacuum Belt Transfer To Keep Board Right Position.
• Lower Folding Belts With Indepentent Ac Motor For Belt Speed Regulating With Touch Screen Display.
• Final Squaring To Correct Fish Tail.

COUNT  EJECTOR

• Down Stacker.
• Up To 30bundles Per Minute.
• Features Included:
• Servo Motor Driven.
• Side Squiring And Correction Motorized Control.
• Linear Guideway Lateral Moving.
• Sheet Bundle Hold-down Delivery Belt.
